Solar Panel 300T

Physical

• Length: 651 mm (25.6 in.)
• Width: 150 mm (5.9 in.)
• Height: 299 mm (11.8 in.)
• Net Weight: 9.2 kg (20.3 lb.)

Dynamic effects

• Electronic dimming: 0 – 100%

Control and programming

• Control options: DMX, RDM, Rotary
• DMX channels: 2/5
• Dimmer frequency: 1.2 – 20.0 KHz
• DMX address setting: Control panel with LED display or via RDM
• DMX compliance: USITT DMX512-A
• RDM compliance: ANSI/ESTA E1.20
• RDM function available for addressing and settings

Optics

• Light source: 2880pcs SMD LED
• Beam angle: 120°
• Color temperature: 3,200K – 5,600K tunable
• Minimum LED lifetime: 50,000 hours

Photometric data

• Full on 570lux @5m
• CRI (Color Rendering Index) : >98(average)
• TM-30 Rf (IES TM-30-15 Fidelity Index): >97(5,600K)
• TM-30 Rg (IES TM-30-15 Gamut Index): >104(5,600K)
• TLCI (Television Lighting Consistency Index): >98(average)
• For more information, please refer to the datasheet

Construction

• Housing: Aluminum
• Color: Black

Installation

• Mounting: Adjustable bracket
• Environment: IP20 indoor use
• Orientation: Any
• Minimum distance to combustible materials: 0.2 m (0.7 ft.)
• Minimum distance to illuminated surfaces: 0.5 m (1.6 ft.)

Connections

• AC power in/thru: PowerCon in & out
• DMX & RDM data in/thru: 3-Pin XLR in & out

Electrical

• AC power: 100–240 V nominal, 50/60 Hz
• Power supply unit: Auto ranging power unit

Typical power and current

• 230 V, 50 Hz: 300W max(turbo mode), PF 0.96
• Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 10%.

Thermal

• Cooling: Forced air (temperature-regulated, low noise)
• Maximum ambient temperature (Ta max.): 40° C (104° F)
• Minimum ambient temperature (Ta min.): -10° C (14° F)

Approvals

• Pending

Included parts

• Power cable
• 8-leaf barndoor
• Safety cable

Optional parts

• Beehive diffuser
