Event 200T

200Watt tunable white LED fresnel manual zoom event exhibition light

Event 200T is a 200Watt WW + 200Watt CW powered dual white LED fresnel light with manual zoom function. The RDM-DMX compliant, 25 – 65 degree manual zoom along with it’s superior 95 CRI make this fixture a good replacement for the traditional fresnels. Color temperature adjustable from 2700k to 6000K. The power stay same when adjust CCT. A barndoor is available to control the shape of the light.

It is designed as a cost effective fresnel fixture for events. Also available in 100Watt power range – Event 100T. The appearance and size for the Event 100T and Event 200T almost same. Difference is inside, heat sink, LED chips, power supply.

Super compact: The Event 200T weighs only 3.6kg, it is super compact and light weight and idea for event and installation.

Color temperature adjustable: CCT adjustable from 2700k to 6000K, and moreover, each color temperature stays same power at 200watt, which means when you adjust color temperature, the brightness says almost same.

Powerful output: 200Watt LED light source, it is more powerful and more energy saving then lamp product. Creating much lower heat.

Beam angle adjustable (Zoom): 25 – 65 degree manual zoom makes it possible to use in short and long distance throw.

High CRI, TLCI, CQS: • Average R9≥95, TLCI 97 means the fixture offers the top notch light quality.

 CDM-T LED replacement: Due to EU policy, CDMT lamp will need to be replaced. And this is a great time and suitable product for the replacement.

Event and exhibition light: Due to the above features, you can find the event 200T is born to be lighting product for event and exhibitions.

Key features

Datasheet

Specifications

Physical

  • Length: 229 mm (9.0 in.)
  • Width: 236 mm (9.3 in.)
  • Height: 290 mm (11.4 in.)
  • Net Weight: 3.6 kg (7.9 lb.) barndoor included

Dynamic effects

  • Electronic shutter effect: Instant open and blackout
  • Electronic dimming: 0 – 100%
  • Strobe and pulse effects: Variable speed and action, random strobe

Control and programming

  • Control options: DMX, RDM, stand-alone
  • DMX channels: 1/2/3/5
  • Dimmer frequency: 1.2 – 24.0 KHz
  • DMX address setting: Control panel with LED display or via RDM
  • DMX compliance: USITT DMX512-A
  • RDM compliance: ANSI/ESTA E1.20
  • RDM function available for addressing and settings

Optics

  • Light source: 200Wram white + 100Watt cool white LED
  • Color temperature: 2,700K – 6,000K optional
  • Minimum LED lifetime: 50,000 hours
  • Zoom Range: 25° – 65° manual zoom

Photometric data

  • Warm white 785lux @5m 25°
  • Cool white 1080lux @5m 25°
  • For more information, please refer to the datasheet

Construction

  • Housing: Stretch aluminum, engineering grade flame-retardant plastic
  • Color: Black

Installation

  • Mounting: Adjustable bracket
  • Environment: IP20 indoor use
  • Orientation: Any
  • Minimum distance to combustible materials: 0.2 m (0.7 ft.)
  • Minimum distance to illuminated surfaces: 0.5 m (1.6 ft.)

Connections

  • AC power in, thru: PowerCon in
  • DMX & RDM data in/thru: 3-Pin XLR in & out(5-pin optional)

Electrical

  • AC power: 100–240 V nominal, 50/60 Hz
  • Power supply unit: Auto ranging power unit

Typical power and current

  • 230 V, 50 Hz: 1.2 A, 200 W, PF 0.96
  • Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 10%.

Thermal

  • Cooling: Forced air (temperature-regulated, low noise)
  • Maximum ambient temperature (Ta max.): 40° C (104° F)
  • Minimum ambient temperature (Ta min.): -10° C (14° F)

Approvals

  • EU safety: EN IEC 60598-2-17:2018, EN 60598-1:2015+A1:2018,
  • EU EMC: EN 55015:2013+A1:2015, CISPR 15:2013+A1:2015, EN 61547:2009, IEC 61000-4-2:2008

Included parts

  • Rotating barndoor
  • Color frame
  • User manual
  • Safety cable

Optional parts

  • Mounting bracket

*Specifications subject to change without notice.*
