PHYSICAL
Length: 745 mm (29.3 in.)
Width: 294 mm (11.6 in.)
Height: 294 mm (11.6 in.)
Net Weight: 8.7 kg (19.2 lb.)
DYNAMIC EFFECTS
Electronic shutter effect: Instant open and blackout
Electronic dimming: 0 – 100%
Strobe and pulse effects: Variable speed and action, random strobe
CONTROL AND PROGRAMMING
Control options: DMX, RDM, ArtNet
DMX channels: 2/8/12
Dimmer frequency: 1.2 – 20.0 KHz
Dimmer curves: Standard/ Stage/ TV/ Architecture/ Theatre
Fan mode: studio mode for super silent operation(reduced power, even lower fan speed)
DMX address setting: Control panel with LCD display or via RDM
DMX compliance: USITT DMX512-A
RDM compliance: ANSI/ESTA E1.20
RDM function available for addressing and settings
OPTICS
Light source: 350W LED
Color mixing: RGBALC(amber, lime, cyan)
Color temperature: 3,000K - 8,000K
Minimum LED lifetime: 50,000 hours
Zoom Range: 18° - 38° manual zoom
PHOTOMETRIC DATA
Red 405lux @5m 18°
Green 680lux @5m 18°
Blue 79lux @5m 18°
Amber 1440lux @5m 18°
Lime 2260lux @5m 18°
Cyan 430lux @5m 18°
Full on 4850lux @5m 18°
For more information, please refer to the datasheet
CONSTRUCTION
Housing: Stretch aluminum, engineering grade flame-retardant plastic
Color: Black
GOBOS & COLOR FRAME
Gobo size: D size, OD 53.3mm, image area 43mm
Color frame size: 140 x 140mm (5.5 in. x 5.5 in.)
INSTALLATION
Mounting: Adjustable bracket
Enviroment: IP20 indoor use
Orientation: Any
Minimum distance to combustible materials: 0.2 m (0.7 ft.)
Minimum distance to illuminated surfaces: 0.5 m (1.6 ft.)
CONNECTIONS
AC power in/thru: PowerCon in & out
DMX & RDM data in/thru: 3-Pin XLR in & out(5-pin optional)
ELECTRICAL
AC power: 100–240 V nominal, 50/60 Hz
Power supply unit: Auto ranging power unit
TYPICAL POWER AND CURRENT
230 V, 50 Hz: 330 W, PF 0.96
Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 10%.
THERMAL
Cooling: Forced air (temperature-regulated, low noise)
Maximum ambient temperature (Ta max.): 40° C (104° F)
Minimum ambient temperature (Ta min.): -10° C (14° F)
APPROVALS
EU safety: EN IEC 60598-2-17:2018, EN 60598-1:2015+A1:2018,
EU EMC: EN 55015:2013+A1:2015, CISPR 15:2013+A1:2015, EN 61547:2009, IEC 61000-4-2:2008
INCLUDED PARTS
Color frame
Safety cable
User manual
OPTIONAL PARTS
Mounting bracket
Gobo holder
Iris
