PHYSICAL
Length: 334 mm (13.2 in.)
Width: 270 mm (10.6 in.)
Height: 509 mm (20.1 in.)
Net Weight: 13.7 kg (30.2 lb.)
DYNAMIC EFFECTS
Color wheel: 9 colors + open
Static Gobo wheel: 9 static gobos + open
Rotating Gobo wheel: 7 rotating gobos + open
Prism: 3 facet circular rotating indexable prism
Focus: motorized
Dimmer/shutter: 0 - 100% continuous dimming, regular and random strobe and pulse effects, instant open and blackout
Pan: 540°
Tilt: 270°
Electronic dimming: 0 – 100%
Strobe and pulse effects: Variable speed and action, random strobe
CONTROL AND PROGRAMMING
Control options: DMX, Auto, master-slave
DMX channels: 18
DMX address setting: Control panel with LCD display
DMX compliance: USITT DMX512-A
OPTICS
Light source: 200W white LED
Color temperature: 6600 K
Minimum LED lifetime: 50,000 hours
Zoom: 7~20° motorized zoom
PHOTOMETRIC DATA
CRI (Color Rendering Index): >73
For more information, please refer to the datasheet
CONSTRUCTION
Housing: Engineering grade flame-retardant plastic
Color: Black
Enviroment: IP20 indoor use
INSTALLATION
Mounting: 2 x Omega brackets
Location: Dry location only, must be fastened to surface or structure
Orientation: Any
Minimum distance to combustible materials: 0.2 m (0.7 ft.)
Minimum distance to illuminated surfaces: 2 m (6.6 ft.)
CONNECTIONS
AC power in, thru: PowerCon in
DMX data in/thru: 3-Pin XLR in & out
ELECTRICAL
AC power: 100–240 V nominal, 50/60 Hz
Power supply unit: Auto ranging power unit
TYPICAL POWER AND CURRENT
230 V, 50 Hz: 200 W
Allow for a deviation of +/- 10%.
THERMAL
Cooling: Forced air
Maximum ambient temperature (Ta max.): 40° C (104° F)
Minimum ambient temperature (Ta min.): 5° C (41° F)
APPROVALS
Pending
INCLUDED PARTS
Two omega brackets with 1/4 turn fasteners
Safety cable
User manual
OPTIONAL PARTS
Clamp
